semi-trailer

I. Tank Body

1. Volume: 35000L, can be configured with 3-6 compartments for different oil products (diesel, gasoline, kerosene). The number of compartments can be adjusted as needed.

2. Tank Material: Q235B high-quality carbon steel, cylinder thickness 6mm (>5.2mm), end cap thickness 6mm, elliptical tank, internal and external anti-corrosion treatment, white paint; aluminum alloy tank body optional for weight reduction.

3. Manholes: 3-6 explosion-proof manholes with breather valves on the top, with safety railings and walkways for convenient filling operations.

4. Unloading System: Bottom-mounted emergency shut-off valve, manual + pneumatic dual control; equipped with European standard unloading port, oil and gas recovery interface, and overflow prevention probe socket.

5. Safety Markings: The tank body is affixed with a diamond-shaped hazardous materials label and a no-smoking warning sign; the volume of each compartment is clearly printed.

II. Axle System

1. Axles: Three-axle Fuhua 13-ton special-purpose axles, high load-bearing capacity, suitable for long-distance heavy-duty transportation.

2. Suspension: American-style mechanical leaf spring suspension, 10 thickened leaf springs, resistant to bumps; air suspension optional.

3. Tires: 12R22.5 tubeless steel wire tires, equipped with aluminum alloy steel rims, one spare tire.

4. Outriggers: JOST 28-ton double-action external outriggers, stable and reliable parking support.

5. Towing Pins: 50# (90# optional) towing pins, compatible with mainstream tractor units.

III. Chassis and Braking Electrical System

1. Chassis Beams: High-strength I-beams, shot-blasted for rust removal, stable welding process, high strength and not easily deformed.

2. Braking System: Dual-circuit air brakes, WABCO valves, spring-loaded parking brake, ABS anti-lock braking system, meeting the safety requirements for dangerous goods transportation.

3. Electrical System: 24V circuit, LED side marker lights and taillights, complete reflective markings, compliant with domestic export regulations.

4. Toolbox: Enclosed toolboxes on both sides for storing tools and accessories.

IV. Accompanying Accessories & Documents

1. Included: Fire extinguisher, fire cap, mudguards, and a set of operating tools.

2. Documents: Vehicle certificate of conformity, tank inspection report, meeting domestic registration and export customs clearance requirements.
